Product Description
The Sightmark Ultra Shot R-Spec Reflex Sight / Dark Earth turns up the heat on your range time with ultra-fast target acquisition and seriously long battery life, from 200 to 2,000 hours on a single CR123A battery. The Ultra Shot R-Spec’s premium wide-angle lens system with scratch resistant and anti-reflective silver coating, 4 illuminated red/green reticle options with 10 brightness settings, parallax correction (beyond 25 yards) and unlimited eye relief deliver a crisp, robust field of view and uncompromising reliability. Built tough, the Ultra Shot R-Spec Reflex Sight / Dark Earth is shock proof, IP55 weather-resistant, recoil rated up to .50 BMG and constructed of a rugged, lightweight 6061-T6 aluminum body and protective shield. 1 MOA windage and elevation adjustments, up to 120 MOA of travel, get you on target quickly and keep you there with an Interlock internal locking adjustment system, for precise, repeatable shooting from any range your comfortable shooting at 1x magnification. The Ultra Shot R-Spec Reflex Sight / Dark Earth also features a low battery indicator, digital switch controls, 1-hour auto shut-off, quick-detach picatinny mount and Sightmark’s lifetime warranty. Includes adjustment tools, CR123A battery, operation manual and neoprene cover.
| Reticle, Type | 4 Pattern - 5 MOA dot, 3 MOA dot with 50 MOA circle, 3 MOA dot with 50 MOA crossshair, 3 MOA dot with 30 MOA circle/crosshair (subtensions total 50 MOA) |
|---|---|
| Reticle, Color | Red and Green |
| Magnification | 1 |
| Reticle Brightness Setting | Off, 1-10 |
| Eye relief (in/mm) | Unlimited in/mm |
| Objective overall dimension (mm) | 33x24 mm |
| Elevation Adjustment | 120 MOA |
| Windage Adjustment | 120 MOA |
| Adjustment Value | 1 MOA |
| Parallax Setting | 25 / 23 yd/m |
| Finish/Color | Matte Black |
| Body Material | Aluminum 6061-T6 |
| Maximum Recoil | .50 BMG Max caliber |
| Waterproof IP Standard | IP55 - water resistant |
| Shockproof | Yes, 8ft / 2.4m |
| Fog Proof | No |
| Lens Coating | AR Silver |
| Nitrogen Filled | No |
| Battery Life | 200 - 2,000 Hours |
| Mount Type | Picatinny |
| Battery Type | CR123A |
| Battery Voltage, V | 3V |
| Width | 1.96 / 50 in / mm |
| Length | 4.33 / 110 in / mm |
| Height | 2.28 / 58 in / mm |
| Weight, oz | 10.7 oz |
| Operating temperature, F/C | -22 to 160 / -30 to 71 F/C |
Included in Package
- Neoprene cover
- Adjustment tools
- Battery
- Manual
Batteries Used
- Type: CR123A
- Quantity: 1
Product Downloads
Features
- Rugged lightweight aluminum alloy housing
- Protective aluminum shield
- Quick detach picatinny mount
- Wide lens provides quick target acquisition
- Slotted windage and elevation adjustments
- Red and green reticle illumination
- Low battery indication
- Digital switch controls
- 10 reticle brightness levels
- 1 hour auto shutoff
- Multiple reticle options
- Scratch resistant lens coating
- Interlock internal locking adjustment system
Built for shooting versatility, the Sightmark T-5 is a magnifier that mounts behind a reflex sight or red dot and provides an absolute co-witness. Instantly change the magnification of your close-range optic from 1x to 5x by using the T-5’s flip-to-side mount. The magnifier’s streamlined, low drag design prevents it from snagging on clothing and equipment and makes the T-5 .7” shorter than the magnifier it’s replacing. Ideal for stretching your AR engagements out to 200 yards, an included LQD mount allows for rapid attaching/detaching in intense shooting situations. The T-5’s aluminum construction is shockproof up to .308 caliber rifles and provides IP55 water resistant protection. Brightness and resolution are improved from fully multi-coated optics and external windage and elevation adjustments help shooters align the reticle of their red dot/reflex sight to the center of the magnifier’s point of view. The Sightmark T-5 includes flip-to-side LQD mount, adjustment tools and manual.
| Magnification | 5x |
|---|---|
| Objective Lens | 23 mm |
| Diameter, Eyepiece | 1.26/32 in/mm |
| Diameter, Exit Pupil | 4.6 mm |
| Eye relief (in/mm) | 2.25/57 in/mm |
| Field of view, m@100m | 9.8 |
| Field of view, ft@100yd | 29.6 |
| Diopter Adjustment | +3 to -3 |
| Diameter, Tube | 30 mm |
| Maximum Recoil | .308 Caliber |
| Shockproof | Yes |
| Fog Proof | No |
| IP Rating (waterproof) | IP55 - water resistant |
| Finish/Color | Matte black |
| Body Material | Aluminum |
| Lens Coating | Full Multi-coated |
| Mount Type | Picatinny |
| Operating temperature, F/C | -22 to 160 / -30 to 71 F/C |
| Length (in/mm) | 4.72 / 120 in/mm |
| Width (in/mm) | 2.6 / 66.2 in/mm |
| Height (in/mm) | 1.67 / 42.5 in/mm |
Included in Package
- Flip to side LQD mount
- Adjustment tools
- Manual
Product Downloads
Features
- Locking, quick detach mount for quick and easy removal
- External windage/elevation adjustment for reticle alignment
- Absolute co-witness
- Fully multi-coated, scratch resistant
- 5x magnification increases engagement to 200 yards
- EOTech® and Aimpoint® compatible
